Abaqus Mesh Algorithm

Duration: 12m

Enrolled:0

level:Intermediate

Abaqus Mesh Algorithm

How to use advanced partitioning to prepare models for effective meshing
Implementing Sweep Meshing in X, Y, and Z directions to reduce computational cost
Meshing strategies for components with holes and contact regions (e.g., pins and screws)
Selecting appropriate mesh algorithms (Structured, Free, Bottom-Up, Sweep)
Using Mesh Controls and understanding mesh techniques in Abaqus
Verifying and improving mesh quality using the Aspect Ratio Tool
Applying Edit Mesh Tool and node dragging to enhance element quality
Understanding the impact of element size on simulation time and accuracy
Special considerations for meshing in biomechanical models with contact
Optimizing master/slave element size ratios to avoid contact errors

Course Content

Tutorial Video

Meshing Techniques in Abaqus: Part 1- 3D Element

06:34
Meshing Techniques in Abaqus: Part 2- Parts with Hole

05:02

Simulation Files

Student Ratings & Reviews

No Review Yet

How to use advanced partitioning to prepare models for effective meshing
Implementing Sweep Meshing in X, Y, and Z directions to reduce computational cost
Meshing strategies for components with holes and contact regions (e.g., pins and screws)
Selecting appropriate mesh algorithms (Structured, Free, Bottom-Up, Sweep)
Using Mesh Controls and understanding mesh techniques in Abaqus
Verifying and improving mesh quality using the Aspect Ratio Tool
Applying Edit Mesh Tool and node dragging to enhance element quality
Understanding the impact of element size on simulation time and accuracy
Special considerations for meshing in biomechanical models with contact
Optimizing master/slave element size ratios to avoid contact errors

File collection

Tutorial Video

Meshing Techniques in Abaqus: Part 1- 3D Element

06:34
Meshing Techniques in Abaqus: Part 2- Parts with Hole

05:02

Simulation Files

Student Ratings & Reviews

No Review Yet

Description

Product Overview:

Enhancing mesh efficiency in Abaqus is critical for reducing computational time without sacrificing model accuracy. This comprehensive tutorial series dives into advanced meshing techniques within Abaqus/CAE, particularly suited for 3D geometries, models with contact, and components featuring complex topologies such as holes or curved paths.

In this course, you’ll learn how to strategically partition geometry, apply specialized meshing methods like sweep, medial axis, and advancing front, and optimize mesh density based on stress concentration zones. Practical examples and PowerPoint explanations are included to ensure clear understanding, alongside guidance on essential tools like mesh quality verification and node dragging for element refinement.
