Flexural response of concrete-filled seamless steel tubes

undefined

Duration: 16m
Enrolled:0
level:Intermediate

Flexural response of concrete-filled seamless steel tubes

Course Content

Simulation Files

  • Tutorial Video
    00:00
  • Modeling Files

Student Ratings & Reviews

No Review Yet
No Review Yet

Who this product is for :

  • Civil Engineers
  • Engineering students

File collection

Simulation Files

  • Tutorial Video
    00:00
  • Modeling Files

Student Ratings & Reviews

No Review Yet
No Review Yet

Description

Papers abstract:

This paper aims to investigate the flexural behavior of concrete filled tubes (CFSTs) made of seamless steel which can handle more pressure than welded steel. Experimental, Theoretical and Finite Element Analyses are utilized for this purpose. The experimental program consists of four-point bending tests of six CFSTs and three hollow steel tubes (STs) for three different Diameter-to-thickness (D/t) ratios of 7.82, 13.5 and 17.5. The test results included are the moment versus displacement and strains, failure modes and ultimate capacities. The contribution of the concrete infill to the flexural capacity was more significant in specimens with higher D/t ratios. All CFST beams exhibited ductile mode of failure with no local buckling. The experimental moments are compared to theoretical nominal moments calculated by well-known international design codes such as the Architectural Institute of Japan (AIJ), the British Standard (BS), the AISC-LRFD, and the Euro code4. Only the AIJ equations predicted non-conservative capacities particularly at the highest D/t ratio. The other codes and standards were more conservative since they did not consider the effect of concrete confinement in their design equations. Finite Element (FE) simulation of the flexural response of CFST is also conducted by developing a nonlinear 3D model considering both material and geometric nonlinearities. The FE model is verified using the present experimental results and a good agreement was achieved in terms of the moment capacity, the failure mode and the moment mid span deflection curves. In addition, the verified finite element model was used to carry out a parametric study considering wider ranges of D/t ratios and yield strengths.



Product Overview:
This package provides a comprehensive finite element model for simulating the bending behavior of Concrete-Filled Steel Tubes (CFSTs) in Abaqus. The model follows the methodology from the ISI reference paper, ensuring accuracy and validation. Key simulation steps include:

  • Part creation (Steel tube, Concrete core, and Rigid supports)
  • Material modeling using Concrete Damaged Plasticity (CDP) for concrete and an elasto-plastic model for steel
  • Contact definition between steel and concrete with surface interactions
  • Boundary conditions & loading setup to replicate a four-point bending test
  • Post-processing of stress, strain, and damage variables.



In this tutorial, the flexural response of CFSTs is simulated, according to data from the work of Abed et al.

More information

  • This package offers a ready-to-use finite element model for CFST bending analysis, suitable for engineers and researchers interested in composite structures and nonlinear finite element modeling. The tutorial follows a structured workflow from model creation to result extraction, ensuring users can replicate and modify the setup as needed.

Recommended file

Recommended courses

30,00 50,00
30-Day Money-Back Guarantee
Full Lifetime Access
17 people watching this product now!

Material Includes

  • Package Includes the following items:
  • Simulation files:
  • Abaqus files (The INP files are applicable to all versions):
  • CAE
  • INP
  • JNL
  • Instructional video:
  • Concise 16-minute guide to model setup and outputs for CFST bending simulation.
